Overheight frame
Overheight frame
GBM OHF is an automatic telescopic 20 to 45 ft overheight frame to be used together with different parent spreader, including fixed 20 ft frame or telescopic – in crane, reach stacker or straddle carrier for safer and faster handling of oversized cargo, in ISO containers or over-height containers / flat racks (with cargo extending up to 2,500 mm above the corner pockets).
GBM Overheight Frame is attached under any parent spreader with ISO standard and equipped with matching overheight frame lifting lugs.
The cargo is lifted by the twist locks of the spreader, the over height frame twist locks act as “extended legs”to the spreader.
Why choose GBM as your OHF supplier?
If you work in the shipping or logistics industry, you know the importance of efficient and reliable equipment for handling containers. Container spreaders are one of the key pieces of equipment used to safely and quickly lift and position containers. When selecting a container spreader supplier, it is critical to choose a company that offers high quality products, excellent service and a proven track record.
GBM also offers an extensive portfolio of industrial services solutions to further increase spreader availability.
Type of GBM Over-height frame
GBM can provide a varioud design solution(3type) for every requirement and type of terminal which are widely used.
-Automatic hook (with base)
-Manual type
-Fully automatic telescopic(without base)
We can customize all the details according to your needs
GBM Spreader experience in career
8 unit OEM Automatic hook Over-height frame
Project located in China
2 unit OEM Automatic hook Over-height frame
Project located in Thailand
2 unit OEM Automatic hook Over-height frame
Project located in Thailand
6 unit Automatic hook Over-height frame
Project located in Greece
2unit Automatic hook Over-height frame
Project located in Jordan
2unit Automatic hook Over-height frame
Project located in India
RFQ for Over-height frame
Yes, every customer's working condition is different, all of our products can be customized depend on customers' requirements,such as SWL,put your logo on OHF. if need, we also can do BV certification.
Normally shipping grabs in containers FR,which requires careful planning and preparation. Always make sure the over-height frame is secured so it doesn't slide around during transport.
GBM have it own experienced department for safe delivery,utilizing the services of a professional will ensure that the mechanical spreader is securely in place and the container is ready to ship.
Yes, GBM has own installation teams in China,not limited to use, we also have over-sea after-sales service and emergency spare parts reserves.
1. What's the SWL of your crane?
2. What's the type of your crane?
3. What's the working condition of OHF ?
4. Do you need base standard？
| Suitable for operating standard 20’40’ 45’ containers | Suitable for operating standard 20’40’ 45’ containers | ||
| SWL | 50T | SWL | 50T |
| Weight | Hook hanger | Weight | Hook hanger |
| 2.1t | 2.25t | ||
| Hook type chassis | Hook type chassis | ||
| 2.9t | 3.78 t | ||
| Height | 2000mm | Height | 2000mm |
| Application area | The ISO standard containers and gantry for ultra-high cargoes that are used in the loading and unloading department are also used for loading and unloading pallets, which must conform to the ISO standard interface and dimensions. |
Application area | The ISO standard containers and gantry for ultra-high cargoes that are used in the loading and unloading department are also used for loading and unloading pallets, which must conform to the ISO standard interface and dimensions. |
| Drive | All the running process is controlled by the spreader drive, such as: open and close the lock of the transfer; telescopic positioning. |
Drive | All the running process is controlled by the spreader drive, such as: open and close the lock of the transfer; telescopic positioning. |
