Eco-hopper

Short Description:

This GBM ecological hopper/dust-proof hopper/port hopper/ mobile tire hopper/eco hopper is mainly used for the unloading and loading of bulk cargoes. If your port pursues 95% dust removal effect,then the filter bagtype hopper will be your best choice.A bag filter is a dry dust filter. It is suitable for capturing fine, dry, nonfibrous dust. The filter bag is made of woven filter cloth or non-woven felt, and the dust-containing gas is filtered by the filtering effect of the fiber fabric. The action settles down and falls into the ash hopper. When the gas containing finer dust passes through the filter material, the dust is blocked and the gas is purified.

FOB Price: US $0.5 - 9,999 / Piece

Min.Order Quantity: 100 Piece/Pieces

Supply Ability: 10000 Piece/Pieces per Month

Port: Shenzhen

Payment Terms: L/C,D/A,D/P,T/T

Send email to us

Product Detail

Qualifications

Model

Technology

Product Tags

Advantages for GBM Eco-hopper

1. Eco hoppers is eco-friendly solution for unloading dust cargo.The dust removal efficiency is high, generally above 99%, and the dust concentration in the outlet gas of the dust collector is within tens of mg/m3, which has a high classification efficiency for fine dust with sub-micron particle size.

2. Multiple discharge options: to conveyor, to one truck, to two truck,via telescopic chute, through ancillary Material Feeder.

3.Multiple travel options: rail, static or pneumatic tyre mounted and powered and towable travel

4. The port hoppers working efficiency could custom by your need and reach 5000T/H.

Send Us Your Requirement Now

Main structure of port eco hopper

Send Us Your Requirement Now

1.The port eco hopper is composed of a grid plate, a palatal opening and closing door, a gantry structure, a mobile wheel group, bag filter collector and a water pipe spray system, a ladder platform, an electrical control system and a remote control system.

2. The eco-hopper meets the requirements of loading and unloading operations for continuous production of three shifts a day at the port.

3. The eco-hopper has sufficient strength and rigidity, the effective volume of the funnel is about 20-50-100 cubic meters, and the size of the opening above the eco hopper is designed according to the capacity of the grab bucket.

4 There is a grid plate and a vibrator at the entrance of the eco hopper to prevent large pieces of material from entering the hopper and causing material blockage.

5. Remote control in the operating room, the operating range of the wireless remote control is 250m.

GBM eco-hopper experience in career

4unit 60CBM Dust proof hopper
Project located in Philippines

2 unit 50CBM Dust proof hopper
Project located in Ghana

2 unit 100CBM Dust proof hopper
Project located in Cameroon

4 unit 60CBM Dust proof hopper
Project located in Cameroon

4 unit 60CBM Dust proof hopper
Project located in Gambia

2 unit 60CBM Dust proof hopper
Project located in Nigeria

2 unit 80CBM Dust proof hopper
Project located in Tanzania

2 unit 70CBM Dust proof hopper
Project located in Russia

2 unit Cyclone dust-proof hopper
Project located in China

Q&A

Q1. Can the Hopper be customized?

Yes, every customer's working condition is different, all of our products can be customized depend on customers' requirements. Please see the below hopper type we could produce for you:

Bag-filter Dust-proof hopper

Cyclone Dust-control hopper

Tyre mobile Eco hopper

Fixed stationary Eco hopper

Non-dust proof normal hopper

Double discharge feed hopper

Spray dust removal hopper

Rail type port hopper

Q2. How is shippment of dust-proof eco hopper?

Normally shipping goods in containers ,shipping dust hoppers in containers requires careful planning and preparation. Always make sure the hopper is secured so it doesn't slide around during transport.

GBM have it own experienced department for safe delivery,utilizing the services of a professional will ensure that the hopper is securely in place and the container is ready to ship.

Q3. Do you have installation team for install dust-proof hopper?

Yes, GBM has own installation teams in China and overseas,we can provide service even during covid-19.Also, any kind of lifting toolswill available for your instruction.

Q4:What is information do you need for provide drawing?

1.What kind of Bulk Hopper you need, Simple one or Dust proof type?

2. What's the material you usually handle and material density?

3. The hopper capacity do you need?How about the grab capacity, the grab open size?

4. Do you need fixed hopper or mobile hopper Does unloading hopper move by itself or by other machine?

5. Will the eco hopper unloading into truck or conveyor belt,?

6. What's the dust removal efficiencyand the handling efficiency(_T/_h) you want?

Q5:What is documents GBM could support

1) The general layout of the hopper(including the main dimensions and performance parameters) and the structure specification.

2) Layout drawing, assembly drawing and processing drawing of wearing parts of each mechanism of the hopper

3) Electrical equipment system diagram, layout diagram, wiring diagram, and control principle diagram.

4) Cable, conduit or trunking layout.

5) The schematic diagram of the hydraulic system and its description.

6) Product structure diagram of purchased parts, instruction manual and maintenance manual.

Previous: Multifunctional Hydraulic Portal Wharf Crane

Next: Straddle carrier

No.	Model	Volume(m3)	Loading Weight (t)	Hopper Weight (t)	Max.Total Weight (t)	Unloading Capacity(t/h)	Note
001	HP40	40	60	16	80	600	1 outlet eco Hopper
002	HP50	50	80	19	100	800
003	HP60	60	100	21	125	1000
004	HP70	70	120	25	145	1200
005	HP80	80	140	27	170	1600
006	HP100	100	160	30	190	2000
007	HP60-2	60	200	33	235	2500
008	HP70-2	70	120	27	150	2500	2 outlets eco Hopper
009	HP80-2	80	140	30	170	2000
010	HP100-2	100	160	33	195	3200
